Adroit Parabolic Scraper
Loading models...
The Adroit Parabolic Scraper is designed for use on belts where there is limited space and there is a higher wear rate in the centre portion of the belt cover.
The parabolic shape of the blade combined with the rubber torsion tensioner ensures that more tension is placed in the centre of the belt thereby increasing cleaning effectiveness.
Specifications
| Belt Widths | 300 to 2400mm |
| Belt Speeds | < 3.5m/s |
| Material Abrasiveness | Designed for low to very high abrasiveness Wet or dry |
| Material Temperature | Tungsten < 200˚C |
| Reversing or One-Way | One-way |
| Mechanical Joints | No |
| Blade Type | Solid blade full belt width. Can be supplied double sided. |
| Blade Material | Tungsten |
| Tensioner Type | Rubber Torsion Belt width > 1200mm rubber torsion is fitted on telescopic bracket. |
| Frame Material | Galvanised Can be manufactured in stainless steel |
Product Range
| A | B | C | C | |||||||||
| Belt Width | Max Belt Speed | Material Abrasiveness | Reversing Belt or One-way | Mechanical Belt Joints | Blade Type | Blade Material | Tensioner Bracket Type | Standard Material Finish | Overall Length | Scraping Width | Blade Height Single | Blade Height Double |
| mm | m/s | mm | mm | mm | mm | |||||||
| 300 | <3.5 | High | One-way | No | Solid | Tungsten | Fixed Torsion | Galvanised | 1000 | 300 | 100 | 130 |
| 450 | <3.5 | High | One-way | No | Solid | Tungsten | Fixed Torsion | Galvanised | 1150 | 450 | 100 | 130 |
| 600 | <3.5 | High | One-way | No | Solid | Tungsten | Fixed Torsion | Galvanised | 1300 | 600 | 100 | 130 |
| 750 | <3.5 | High | One-way | No | Solid | Tungsten | Fixed Torsion | Galvanised | 1450 | 750 | 100 | 130 |
| 900 | <3.5 | High | One-way | No | Solid | Tungsten | Fixed Torsion | Galvanised | 1600 | 900 | 130 | 130 |
| 1050 | <3.5 | High | One-way | No | Solid | Tungsten | Fixed Torsion | Galvanised | 1750 | 1050 | 130 | 130 |
| 1200 | <3.5 | High | One-way | No | Solid | Tungsten | Fixed Torsion | Galvanised | 1900 | 1200 | 150 | 150 |
| 1350 | <3.5 | High | One-way | No | Solid | Tungsten | Fixed Torsion | Galvanised | 2050 | 1350 | 150 | 150 |
| 1500 | <3.5 | High | One-way | No | Solid | Tungsten | Fixed Torsion | Galvanised | 2200 | 1500 | 150 | 150 |
Telescopic Set
