PU Solid Blade Primary Scraper
Loading models...
Solid polyurethane blade primary scraper. Segments are 129mm or 259 mm high by 200mm wide that are securely bolted onto the carrier bar. Simple and effective spring tensioning system requiring very little to no maintenance.
Effective, reliable and compact primary scraper used across all mining and industrial applications. Will be matched with a T.I.S standard bar scraper to yield the optimum belt cleaning solution.
Specifications
| Belt Widths | 300 to 2100mm |
| Belt Speeds | < 3.5 m/s |
| Head Pulley Diameter | < 600mm |
| Material Type | Designed for low to medium abrasiveness. Wet and sticky. |
| Material Temperature | < 60˚C |
| Reversing or One-Way | One-way |
| Mechanical Joints | Yes |
| Blade Type | Solid blade 129mm or 259mm high |
| Blade Material | Polyurethane 80 ShoreA |
| Tensioner Type | Spring |
| Frame Material | Galvanised Can be manufactured in stainless steel |
Product Range
| A | B | C | ||||||||||
| Belt Width | Max Belt Speed | Head Pulley Diameter | Material Abrasiveness | Reversing Belt or One-way | Mechanical Belt Joints | Blade Type | Blade Material | Tensioner Bracket Type | Standard Material Finish | Overall Length | Scraping Width | Blade Height |
| mm | m/s | mm | mm | mm | mm | |||||||
| 300 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 1000 | 300 | 129 |
| 450 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 1150 | 450 | 129 |
| 600 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 1300 | 600 | 129 |
| 750 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 1450 | 750 | 129 |
| 900 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 1600 | 900 | 129 |
| 1050 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 1750 | 1050 | 259 |
| 1200 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 1900 | 1200 | 259 |
| 1350 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 2050 | 1350 | 259 |
| 1500 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 2200 | 1500 | 259 |
| 1650 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 2350 | 1650 | 259 |
| 1800 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 2500 | 1800 | 259 |
| 2100 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 2800 | 2100 | 259 |
| 2400 | <3.5 | < 600 | Low | One-way | No | Solid | Polyurethane | Fixed Spring | Galvanised | 3100 | 2400 | 259 |
